Amgo BP-9, 9000 lb 2 Post Car Lift - Low Ceiling

Amgo BP9 2 Post Car Lift

The AMGO BP-9 Base Plate Two Post Lift is a reliable and space-efficient solution designed for professional workshops with low ceiling heights. With a robust 9,000 lb lifting capacity, this lift easily handles passenger cars, light trucks, and SUVs. Its base plate design allows installation in shops with ceilings as low as 9 feet, making it an ideal choice for service bays where overhead clearance is limited without compromising lifting performance or stability.

Engineered for safety and ease of use, the BP-9 features AMGO’s exclusive dual safety lock structure combined with a single-point manual safety release, allowing both columns to unlock simultaneously from one side. The symmetric 3-stage retractable arms provide excellent reach and flexibility, while self-lubricating UHMW sliders and automatic arm restraints ensure smooth operation, durability, and long-term reliability in demanding shop environments.

Amgo BP 9 9000 lb 2 Post Lift Specifications:

• Lifting Capacity: 9,000 lbs

• Lift Type: Base Plate Two Post Lift

• Lifting Time: 37 seconds

• Max. Lifting Height (w/o Extension): 71 1/4" – 72 1/2"

• Max. Lifting Height (w/ Extension): 74 3/16" – 75 1/2"

• Max. Lock Height (w/o Extension): 69 5/8" – 70 15/16"

• Max. Lock Height (w/ Extension): 72 5/8" – 73 7/8"

• Overall Height: 108"

• Overall Width: 131 7/8"

• Drive-Thru Clearance: 99"

• Width Between Columns: 109 7/16"

• Minimum Pad Height: 3 5/16"

• Motor: 2.0 HP, 220V / 60Hz, Single Phase

• Gross Weight: 1,321 lbs

• Shipping Weight: 1,305 lbs

• Container Quantity: 25 Units / 20' GP

• Pallet Dimensions: 112" L × 18" W × 31" H

• Amgo 5-3-2 Warranty (5 year steel structure, 3 year hydraulic parts, 2 years on electrical components)

• Motor: 2.0HP, 220v/60Hz, single phase

BP-9, 9000 lb 2 Post Car Lift Special Features

• Heavy-duty 9,000 lb capacity ideal for daily shop use

• Base plate design suitable for low-ceiling installations

• Symmetric 3-stage retractable arms for wide vehicle coverage

• Dual safety lock structure for enhanced operator protection

• Single-point manual safety lock release unlocks both columns simultaneously

• Automatic arm restraints for added safety during lifting

• Self-lubricating UHMW polyethylene sliders for smooth, low-maintenance operation

• Aero sync cables included as standard

• Single-screw rubber pads with 3" extension adapters included

• Detachable toe guards and tool trays for added convenience

BP-9 Manual

  Amgo BP-9 Manual

  Amgo BP-9 Installation Instruction

BP-9 Car Lift Optional Items (sold separately):

• Saddle Adapter - Light Truck: No. 20804

• Saddle Adapter - Heavy Duty Truck: No. 21103
