Amgo MRL09, 9000lb Mid-rise Scissor Lift

MRL09 Mid-Rise Scissor Lift by Amgo

Looking for a Lift That Works for Low-Clearance Vehicles? The Amgo MRL09 9,000-lb Mid-Rise Scissors Lift is the perfect solution for service bays that handle a wide range of vehicles, including ultra-low clearance cars. With its innovative two-stage runway design, this lift provides a low-profile entrance, allowing vehicles to drive in from either side with ease. The MRL09's sleek and functional design makes it the ideal choice for quick service applications, offering fast setup and minimal maintenance.

Engineered for efficiency and reliability, the MRL09 features dual hydraulic synchronization and a hydraulic locking system, ensuring smooth and secure lifting. Its extendable platforms accommodate various wheelbases, making it versatile for different vehicles. Whether you're working on standard cars or low-clearance vehicles, the MRL09 delivers quick and safe service, with a lifting capacity of 9,000 lbs.

Scissor Lift MRL09 Specification:

• Model: MRL09

• Lifting Capacity: 9,000 lbs

• Lifting Time: 30s

• Max. Lifting Height (A): 47 1/4"

• Minimum Height (B): 5 5/16"

• First Stage Ramp Height (C): 2 3/8"

• Overall Length (Incl. Ramp) (D): 156 11/16"

• Overall Width (E): 76 3/4"

• Width Between Runways (F): 29 1/2"

• Runway Length (G): 61 7/16" – 77 3/16"

• Motor: 2.0 HP-220v

• Pallet Dimension:
  • Pallet 1: 67" x 24" x 26"

  • Pallet 2: 19" x 17" x 48"
  • Total Weight: 1,821lbs
  • This unit is available for Lift Gate Service

MRL09, 9000lb Mid-rise Scissor Lift Special Features

• Low profile design with a minimum height of 2 3/8" for ultra-low clearance vehicles

• Dual two-stage drive-in ramps for easy double entrance

• Installation Options: Flush Mount (In Ground) or Surface Mount

• Dual hydraulic synchronization and hydraulic locking system for smooth operation

• No extra air source required for operation

• Extendable platforms accommodate various wheelbases

• Mid-rise design with thickened steel scissors for added durability

• ETL certified AMGO power unit for reliable power

• Both 1 1/2" and 3" rubber pads come standard

Warranty

• Steel structure: 5 years

• Hydraulic components, bronze bushings, slider blocks, plastic parts: 3 years

• Electrical components and cables: 2 years

• Rubber pads: Not covered

MRL09 Manual

 Amgo MRL09 Manual

 Amgo MRL09 Installation Instruction
