Amgo PRO 12SX 12,000lb 4 Post Lift

PRO-12SX 4 Post Car Lift by Amgo

Need Extra-Wide Drive-Through Clearance for Easier Vehicle Access? The Amgo PRO-12SX 12,000-lb 4 Post Lift is designed for shops that need more space, comfort, and flexibility when servicing a wide range of vehicles. With an impressive drive-through clearance of over 100 inches and an extra-wide column spacing of more than 118 inches, this lift makes driving on and off smoother and safer than most standard four-post lifts on the market.

Built for daily commercial use, the PRO-12SX combines heavy-duty construction with advanced safety systems. It features stepless adjustable runways, non-skid diamond platforms, and a cable-driven lifting system using aircraft-grade cables. With a 12,000-lb capacity and an ETL-certified power unit, this lift is an ideal solution for professional garages and service shops handling cars, SUVs, pickups, and vans. The Pro-12SX is backed by Amgo's 5-3-2 warranty, ensuring long-lasting performance.

PRO 12SX Specifications:

• Model: PRO-12SX

• Lifting Capacity: 12,000 lbs

• Lifting Time: 45s

• Overall Length (Incl. Ramps) (A): 232 5/8"

• Outside Edge of Crossbeams (B): 190 9/16"

• Overall Width (C): 132 1/8"

• Width Between Columns (D): 118 1/8"

• Max. Lifting Height (E): 74 7/16"

• Max. Lock Height to Top of Runway: 71 1/4"

• Overall Height (F): 86"

• Minimum Height (G): 6 11/16"

• Max. Underneath Height (H): 68 7/8"

• Max. Lock Underneath Runway: 65 3/4"

• Drive-Thru Clearance (I): 104 3/16"

• Width Between Runways (J): 43 5/16"

  • Min: 35 7/16"

  • Max: 53 3/4"

• Outside Edge of Runways (K): 83 5/16"

  • Min: 75 7/16"

  • Max: 93 3/4"

• Gross Weight: 2,229 lbs

• Motor: 2.0 HP

• Pallet Dimension: 200"23"29

Amgo 12k Lift Special Features:

• 12,000-lb lifting capacity for a wide range of vehicles

• Extreme wide design with 118 1/8" between columns

• Drive-through clearance over 100" for easier vehicle positioning

• Mechanical self-locking safety device with air-driven lock release

• Primary multiple safety locks and cable-slack protection system

• Cable-driven lifting using aircraft-grade high-quality cables

• High-standard hydraulic cylinder with premium oil seals and compensation valve

• Stepless adjustable width between platforms

• Non-slip diamond platforms for added safety

• ETL certified AMGO power unit

• Oil-water separator and solenoid air valve installed on power side column

Warranty

• 5-Year Warranty: Steel structure

• 3-Year Warranty: Hydraulic components, bronze bushings, slider blocks, plastic parts

• 2-Year Warranty: Electrical components and cables

• No Warranty: Rubber pads

PRO-12SX Manual

   Amgo PRO-12SX Manual

   Amgo PRO-12SX Installation Instruction

Amgo 12000lb 4 Post Car Lift Optional Items (sold separately):

• J6H - Rolling Jack Manual

• J6A - Rolling Jack Pneumatic

• Led lights: No. 40103

• Extension kit: No. 40903 (Adds 26" to runway length)

• Optional airline kit: No. 40102
