BendPak HDS 27X 27,000lb 4 Post Lift - Extended Length; ALI Certified

HDS-27X 27,000lb 4 Post Lift by BendPak

For shops tackling oversized vehicles like Class 7 semi-trucks and city buses, the BendPak HDS-27X is the heavy-duty lift you’ve been waiting for. With a 27,000-lb. capacity and extended 317.5-inch runways, this four-post lift is engineered for power, precision, and reliability. Safety is paramount, featuring spring-loaded locks, a secondary lock system, and a flow restrictor for smooth operation. Its ergonomic design and fully enclosed hydraulic components ensure seamless functionality in even the busiest commercial settings.

Built to last, the HDS-27X boasts galvanized lifting cables, 12” cable sheaves, and reinforced base plates for stability and durability. Optional rolling bridge jacks expand its versatility, making it perfect for wheel service tasks. Whether you’re handling city buses or large fleet vehicles, this CE-certified lift delivers top-tier performance, giving your shop the strength it needs to handle any challenge.

HDS27X Specification

• Total Lifting Capacity: 27,000 lbs

  • Front Axle Max: 13,500 lbs

  • Rear Axle Max: 13,500 lbs

• Minimum Runway Height: 9.5"

• Maximum Rise: 60"

• Maximum Lifting Height: 69.5"

• Time to Full Rise: 75 seconds

• Overall Width: 153.5"

• Outside Length: 317"

• Overall Length: 372.75"

• Height of Columns: 91.25"

• Width Between Columns: 133.5"

• Drive-Thru Clearance: 109"

• Runway Width: 22"

• Runway Length: 315.5"

• Width Between Runways: 40" or 45.25"

• Runway Centerline: 67.25" or 72.5"

• Outside Edge of Runways: 89.25" or 94.5"

• Minimum Wheelbase:

  • Rated Capacity: 230"

  • 75% Capacity: 195"

  • 50% Capacity: 165"

  • 25% Capacity: 130"

• Locking Positions: 13

• Lock Spacing: Every 4"

• Motor: 220 VAC / 60 Hz / Single Phase

• Noise Level: 45 dB

• Shipping Weight: 6,944 lbs

• Shipping Dimensions: 326" x 27" x 36"

BendPak HDS27X 27,000lb 4 Post Lift Special Features

• CE Approved and Certified, meets or exceeds European Standard EN-1493

• Supersized 12" diameter cable sheaves

• Galvanized lifting cables

• Grease nipples for lubrication

• Single hydraulic under-runway cylinder with integrated flow restrictor

• Durable powder-coated finish

• Spring-loaded safety locks with second lock system on constant guard

• Fully enclosed lifting cables

• Multiple adjustable height locking positions

• Maintenance-free electric hydraulic power system

• Conveniently positioned operator controls

• 12" x 12" base plates

• Runways feature a durable matte finish

• Optional rolling jacks

• Warranty
  • 5 Year - Lift Structure
  • 2 year - Hydraulic Unit & Power Unit
  • 1 Year - Electrical and Operating Components
  • *Reasonable labor costs covered for first 12 months

BendPak HDS-27X Manual

  BendPak HDS 27X Operations Manual

  HDS-27X Brochure

Warehouse Pickup Locations: $1500 Pickup Discount Available - Contact us for more information!

• Santa Paula, CA 93060
• Theodore, AL 36582

A - Min. Runway Height: 8.5" (216 mm)
B - Max. Rise: 58.5" (1,480 mm)
C - Max. Lifting Height: 69.5" (1,765 mm)
D - Overall Width: 153.5" (3,899 mm)
E - Outside Length: 317.5" (8,065 mm)
F - Overall Length: 372.75" (9,468 mm)
G - Height of Columns: 91.25" (2,318 mm)
H - Width Between Columns: 133.5" (3,391 mm)
I - Drive-Thru Clearance: 109" (2,769 mm)
J - Runway Width: 22" (559 mm)
K - Length of Runways: 317.5" (8,065 mm)
L - Width Between Runways: 40" (1,016 mm) or 45.5" (1,156 mm)
M - Runway Centerline: 62" (1,575 mm) or 67.5" (1,715 mm)
N - Outside Edge of Runways: 84" (2,134 mm) or 89.5" (2,273 mm)
