Challenger CL10A-XP9 9,000lb 2 Post Lift - Adjustable Width; ALI Certified

CL10A-XP9 9K 2 Post Lift

Maximize efficiency in your express service bay with the Challenger CL10A-XP9 9K Two-Post Drive-On Pad Lift. Designed for speed and simplicity, this innovative lift features drive-on pads that allow for quick and accurate vehicle positioning on the first try—reducing setup time and boosting shop productivity. Ideal for high-volume environments, the CL10A-XP9 ensures smoother workflow and less technician frustration with every lift.

Take performance even further with QuickCycle™ technology, delivering an ultra-fast 27-second rise and 17-second lowering time on select models. With adjustable height and width options, plus dual pendant controls available, this lift adapts to your shop’s needs while maintaining reliable performance. ALI/ETL Certified for safety and quality, the CL10A-XP9 is the ultimate solution for service professionals looking to increase throughput and efficiency.

CL10A XP9 Series Specification

• Lifting Capacity: 9,000 lbs

• Lifting Configuration: Drive-on express pad

• Rise Height: 70″

• Overall Height: 140″

• Overall Height (Cylinder Extended): 143″


• Adjustable Overall Width: 138.5″-143"

• Drive-Thru Clearance: 90″

• Floor to Overhead Switch: 134.5″

• Platform Height: 2.25″

• Platform Width: 24″

• Platform Length: 58″ / 66.5″ / 75″

• Width Between Platforms: 31.5″

• Inside Columns: 110″

• Motor / Voltage:

  • 2HP, 208–230V, 60Hz, 1Ph (Standard)

  • 3HP, 208–230V, 60Hz, 1Ph (QuickCycle™ Models)

• Speed of Rise:

  • 38 seconds (Standard & DPC Models);

  • 27 seconds (QuickCycle™ Models)

• Ceiling Height Required: 144″

• Certification: ALI/ETL Certified

• Colors Available: Red, Blue, Black

• Concrete Requirements: Minimum of 4"-3500psi

CL10A-XP9 Series Two-Post Lift Special Features

• Drive-on express pad design for quick and accurate vehicle spotting

• Ideal for high-efficiency express service bays

• QuickCycle™ technology for faster lifting and lowering (select models)

• Dual pendant control option for improved operator convenience

• Adjustable height and width for flexible installation

• Low-profile platforms for easy vehicle access

• Reduces setup time and increases shop productivity

• Durable construction for long-term reliability

• User-friendly operation for technicians

• Meets strict safety standards with ALI/ETL certification

Challenger CL10A-XP9 Series Manual

  Challenger CL10A-XP9 Series Installation and Operations Manual

  Challenger CL10A-XP9 Series Spec Sheet
