Challenger CL4P9 Series 9000lbs 4 Post Storage Lift - ALI Certified

CL4P9 Series 9000lbs 4 Post Lift

Upgrade your garage or shop with the heavy-duty performance of the Challenger Lifts CL4P9 4-Post Storage Lift, designed to solve space limitations and streamline vehicle storage. Struggling to fit multiple vehicles or manage limited workspace? This ALI-certified 9,000 lb lift delivers the strength and flexibility needed to safely stack vehicles while maintaining easy access and organization—perfect for both residential garages and commercial environments.

Built for maximum versatility, the CL4P9 series is available in Standard, Extended, and Wide configurations to match your exact space and vehicle requirements. With larger columns, enhanced base plates, and increased lifting height, this model provides superior stability and performance compared to smaller lifts. Combined with single-point lock release, adjustable lock ladders, and no anchoring requirement, it offers a powerful, flexible, and hassle-free storage solution that elevates your workflow.

4 Post Storage Lift CL4P9 Specification

CL4P9S (Standard Model)

• Lifting Capacity: 9,000 lbs


• Overall Length: 209.5"


• Overall Width: 112.25"


• Inside Columns: 95"


• Between Columns: 160.5"


• Column Height: 84.5"


• Runway Height: 7"


• Runway Width: 20"


• Width Between Runways: 38"


• Rise Height: 73.25"


• Clearance Height: 67.75"


• Max Wheelbase: 155"


• Crossbeam Clearance: 68"


• Minimum Bay Size: 132" × 264"

CL4P9X (Extended Model)

• Lifting Capacity: 9,000 lbs


• Overall Length: 233.5"


• Overall Width: 112.25"


• Inside Columns: 95"


• Between Columns: 184.75"


• Column Height: 96.5"


• Runway Height: 7"


• Runway Width: 20"


• Width Between Runways: 38"


• Rise Height: 85.5"


• Clearance Height: 80"


• Max Wheelbase: 179"


• Crossbeam Clearance: 80"


• Minimum Bay Size: 132" × 264"

CL4P9W (Wide Model)

• Lifting Capacity: 9,000 lbs


• Overall Length: 233.5"


• Overall Width: 127.25"


• Inside Columns: 110"


• Between Columns: 185.75"


• Column Height: 96.5"


• Runway Height: 7"


• Runway Width: 20"


• Width Between Runways: 38"


• Rise Height: 85.5"


• Clearance Height: 80"


• Max Wheelbase: 179"


• Crossbeam Clearance: 80"


• Minimum Bay Size: 168" × 264"

Common Specifications

• Motor: 1HP / 2HP


• Voltage: 115V / 230V (Single Phase)


• Lifting Speed: 120 / 60 seconds


• Certification: ALI / ETL Certified


• Color: Black


• Concrete Requirements: Minimum of 4"-3500psi

CL4P9 9000lbs 4 Post Storage Lift Special Features

• 9,000 lb lifting capacity for cars, SUVs, and light trucks


• Available in Standard (CL4P9S), Extended (CL4P9X), and Wide (CL4P9W) models


• ALI/ETL certified for safety and reliability


• Up to 85.5" rise height for service applications


• Up to 80" clearance height for vehicle storage


• Larger columns and base plates for enhanced stability


• Adjustable lock ladders for uneven floor installations


• Single-point manual lock release system


• Commercial-grade formed runways for durability


• Built-in runway rail system for optional accessories


• No air required for operation


• No anchoring required to maintain certification


• Powder-coated finish for long-lasting protection

Challenger CL4P9 Manual

  Challenger CL4P9 Series Installation and Operations Manual

  Challenger CL4P9 Series Spec Sheet
