Challenger EV1020 Series 10K Inground - ALI Certified

EV1020 Inground Lift

Increase your shop’s efficiency with the Challenger Lifts EV1020 Series 10,000 lb Inground Drive-On Pad Lift, engineered for fast, accurate vehicle positioning in express service bays. Traditional lifts can slow workflow with difficult spotting and added setup time. The EV1020 solves this with drive-on pads that make loading quick, simple, and precise helping your technicians get to work faster.

Built for durability and smooth performance, the EV1020 features rugged chrome pistons, a non‑breathing ram cylinder for extended life, and a fully sealed cassette tub to eliminate hydraulic leaks. Mechanical locks engage every 3″ for ergonomic working heights.  With a robust 10,000 lb capacity and ALI/ETL certification, this lift delivers professional performance and reliability for busy shops.

Inground Lift EV1020 Series Specification

• Model: EV1020

• Lifting Capacity: 10,000 lbs

• Rise Height: 74″

• Minimum Pad Height: 3.875″ – 6″ (screw pad)

• Pad Capacity: 2,500 lbs per arm

• Guide Plunger Diameter: 8.5″

• Overall Width: 97″

• Drive‑Thru Clearance: 87″

• Motor: 2HP, 208–230V, 60Hz, Single Phase

• Speed of Rise: 38s

• Air Supply Required: 90–120 psi

• Certification: ALI/ETL Certified

• Color Available: Red, Blue, Black

• Concrete Requirements: Minimum of 6"-3500psi

EV1020 Series 10K Inground Drive-On Pad Lift Special Features

• 10,000 lb lifting capacity

• Drive-on pad design for quick vehicle spotting

• 8.5″ chrome pistons for superior load stability

• Chrome non‑breathing ram cylinder for long service life

• Enhanced wiper seals keep contaminants out of bearings

• Mechanical lock engages every 3″ for ergonomic lift heights

• Stainless steel air lock release cylinder resists corrosion

• Fully sealed polymer cassette tub prevents hydraulic leaks


• Powder‑coated finish for lasting durability

• ALI/ETL certified for safety and quality

Challenger EV1020 Series Manual

  Challenger EV1020 Series Installation and Operations Manual

  Challenger EV1020 Series Spec Sheet
