Eagle EB-66 Wheel Balancer

EB-66 Advanced Wheel Balancer with LED Display

The Eagle EB-66 Wheel Balancer delivers cutting-edge Italian technology for professional automotive shops. Equipped with a high-resolution LED digital display and intuitive touch controls, this balancer provides fast, precise readings while maintaining durability for over 200,000 touch cycles. Its low-power, energy-efficient 90W motor reduces operating costs while offering consistent performance for daily shop operations.

Designed with user-friendly software, the EB-66 supports both manual and automatic acquisition of wheel diameter, distance, and width. The machine offers five ALU balancing programs and two ALU smart programs, along with optimization and weight-splitting functions, making it suitable for a wide variety of alloy and steel wheels. Calibration is quick and easy, ensuring the balancer maintains its precision over time.

This balancer can handle wheels with diameters from 10″ to 28″ and weights up to 154 lbs (70 kg). The 40mm balancing shaft allows compatibility with standard accessories, and optional motorcycle adapters expand its versatility. The machine automatically enters standby mode when idle, improving energy efficiency and protecting components for long-lasting performance.

Wheel Balancer EB-66 Specification

• Rim Diameter: 10″–28″

• Max Wheel Weight: 70 kg / 154 lbs

• Max Wheel Diameter: 1118 mm / 44″

• Rim Width: 1.5″–20″

• Precision: ±1 g

• Motor Power: 0.09 kW / 90W

• Power Supply: 100 / 230V, 1PH

• Rotation Speed: 140 RPM

• Balancing Time: 7 seconds

• Second Time Mounting Test: ≤5g

• Machine Dimensions: 61.02″ × 45.67″ × 48.94″ (1550 × 1160 × 1243 mm)

• Packing Dimensions: 42.13″ × 29.92″ × 45.28″ (1070 × 760 × 1150 mm)

• Gross Weight: 132 kg / 291 lbs

EB-66 Wheel Balancer Special Features

• Italian software with high-resolution LED display

• Fast 7-second balancing cycle

• Manual and automatic wheel dimension acquisition

• 5 ALU balancing programs and 2 ALU smart programs

• Optimization and weight split functions for precision

• 40mm balancing shaft for standard accessories

• Optional motorcycle adapters

• Low-power 90W motor for energy efficiency

• Automatic standby mode when idle

• 1 Year Warranty

EB-66 Manual

  Eagle EB-66 Spec Sheet
