Elephant YA Lever Chain Hoist 19,800 lb

YA Lever Chain Hoist by Elephant Lifting Products

The Elephant YA Lever Chain Hoist combines robust specifications with advanced features tailored for heavy-duty lifting tasks. With a hefty capacity of 19,800 pounds and available lift heights of 5', 10', 15', or 20', it excels in a wide range of industrial applications. Engineered for durability, its Grade 105 galvanized load chain adheres to the stringent German DIN 5684 standard, ensuring reliable performance under demanding conditions. The hoist boasts a rounded lever design for seamless operation against flat surfaces and features true one-touch free spooling, which automatically engages brakes upon load application for enhanced safety and control. Its electro-deposited black finish on the hoist body provides superior corrosion resistance, complemented by hardened steel bushings in internal side plates that support the load sheave and pinion with exceptional reliability.

Manufactured in Japan to premium standards, this hoist is equipped with redesigned hooks featuring tip-supporting safety latches, an electro-deposited coating on critical components to resist corrosion, and nickel-plated internal disc hub and ratchet wheel for added durability. With a wide temperature range tolerance from -20°C to +130°C (-4°F to +266°F), the Elephant YA Lever Chain Hoist stands as a dependable choice for rigorous lifting operations across various industries.

Lever Chain Hoist YA Specifications:

• Capacity: 19,800 LBS
• Lift Heights: 5', 10', 15', or 20'

YA 19,800 lb Lever Chain Hoist Special Features:

• Rounded lever design for smooth operation when placed against flat surfaces.
• Grade 105 galvanized load chain, which adheres to the strict German DIN 5684 standard
• True one touch free spooling which automatically brakes when a load is applied
• Redesigned hooks with tip supporting safety latch
• Hoist body has an electro-deposited black finish for corrosion resistance
• Ratchet recovery of 16.5o for 0.8t~1t and 14o for 1.6t~12t
• Internal side plates have hardened steel bushings for excellent load sheave & pinion support
• Internal side plates, pinion, pawls, and pawl springs have an electro-deposited coating that helps resist corrosion
• Internal disc hub and ratchet wheel are nickel plated for corrosion resistance
• Suitable for operation within a -20o to +130o C,  -4o to +266o F temperature range
• Manufactured in Japan - Premium Quality
• THIS ITEM SHIPS FOR FREE!


Elephant YA Documentation:

   Elephant YA Lever Chain Hoist Product Manual
  Elephant YA Lever Chain Hoist Product Catalog
  Elephant YA Lever Chain Hoist Product Breakdown
  Elephant YA Lever Chain Hoist Product Promotional
