Katool KT-X95 8,000lb Full Rise Scissor Lift - Pneumatic Lock

SKU KT-X95
by Katool
  • No Sales Tax - Except CA, FL, IL, IN, MI, & OH
  • Ships in 3-5 Business Days
  • Free Warehouse Pickup Options
  • Better Business Bureau (BBB) Accredited
$4,700.00
Free Warehouse Pickup Locations
Subject to Availability - Call/Text Email to confirm (1-800-474-6537; info@heavyliftdirect.com)
Address Type (Required Field)
Delivery Options (Required Field)
*We will find nearest location
Support Bars

Notify me when back in stock

KT-X95 Full Rise Scissor Lift by Katool

The KT-X95 is a versatile powerhouse that takes lifting to new heights – LITERALLY! This state-of-the-art hydraulic lift isn't just for gearheads and mechanics. With its impressive 8,000-lb capacity and 72-inch maximum lift height, the KT-X95 tackles a wide range of tasks, transforming your workspace into a place of ultimate efficiency. This lift boasts a rapid 50-second lifting time, streamlining your workflow and maximizing productivity. The spacious 58.9-inch platform length and 24.4-inch width comfortably accommodate everything from motorcycles and lawnmowers to heavy furniture and construction materials - if you so need it for that.

The KT-X95’s 2.2kw motor and 20MP rated oil pressure ensure effortless handling of even the most demanding jobs. Meanwhile, self-lubricated parts reduce maintenance, while the flush mount design seamlessly integrates into your workspace. And for continuous operation without overheating, the top-level hydraulic system features a fan-cooled aluminum motor. From automotive enthusiasts looking to stack their car collection to professional mechanics, contractors, and DIYers, the KT-X95 is the ultimate lifting solution.

Scissor Lift KT-X95 Specifications:

  • Max. lifting capacity: 8000lbs
  • Lifting height: 72.3 inch
  • Lifting time: 50S
  • Platform length: 58.9 inch
  • Platform width: 24.4 inch
  • Motor power: 2.2kw
  • Rated oil pressure: 20MP
  • Air pressure: 6-8kgf/c
  • Oil: AW-46 or AW-32 (colder climates)
  • Optional: Support Bars
    • Overall Length: 73"
    • Pin Distance: 48" to 59" Wide
    • Adapter Height: 6.2" to 8" Tall

KT-X95 From Katool Special Features:

  • 8000lbs lifting capacity
  • Lock Style: Pneumatic
  • CE Approved and Certified. It has adopted the 115% dynamic loading capacity standard and was 150% static loading capacity tested
  • Flush mount design
  • Starting-up system design
  • 24V safe control system
  • Height limit switch
  • Composite rubber lifting blocks included
  • Comes with self-lubricated bushing and bearing
  • Drive-up ramps lock design as platform extension for long vehicles
  • Top-level hydraulic system and aluminum motor with the fan on top to avoid overheating caused by long time working
  • The unit needs to be connected to a compressed air source.
  • Includes: Caster Kit for Mobility
  • Power: 220V/60Hz, single phase
  • Katool Warranty:
    • One-year (12 months) warranty on all parts and against all product defects, free of charge to our customers, on all equipment.
    • Vehicle lifts will include an additional three-year (36 months) warranty on all lift structural components only.
*This model should be securely anchored to concrete before operation. Concrete thickness must be at least 5.9" with a 3000 PSI rating. Failure to install this lift on the proper concrete, could result in serious injury or death! It is the customer's responsibility to verify concrete thickness and strength before purchase and installation.

                          This Item has a FLAT RATE SHIPPING FEE: $199*

                          Warehouse Pickup locations (free shipping) - Contact Us if interested.

                          • City of Industry, CA 91789
                          • Brookshire, TX 77423
                          • Houston, TX 77064
                          • Pooler, GA 31322
                          • Jersey City, NJ 07305
                          • Bolingbrook, IL 60440

                          Pallet Dimensions:

                          • Lift: 67" x 26" x 17" - 1,658lbs
                          • Control Unit: 43" x 23" x 18" - 144lbs

                          Scissor Lift Support Bar Kit Diagram
