LMC Lincoln T004 2500 Multi-Use Tire Vulcanizer

Lincoln-2500 Multi-Use Tire Vulcanizer

Replacing large agricultural, construction, logging, and off-the-road tires can be expensive when repairs are still possible. The LMC Lincoln-2500 Multi-Use Tire Vulcanizer is designed for repairing light and medium construction equipment, agricultural tractors, logging skidders, and mining equipment, providing a dedicated solution for large tire repair applications.

The Lincoln-2500 accommodates mid-range tires from 20.5 x 25 through OTR sizes up to 29.5 x 35, as well as skidder tires up to 30.5 x 32. Its Adjust-A-Plate contour system uses 8" x 11" inside and 8" x 15" outside plates to conform to tire contours for tread, shoulder, and sidewall repairs.

An air-actuated pressure system applies more than 5,000 lbs. of pressure evenly across the repair area, while thermostatically controlled heat units maintain the required curing temperature. A built-in five-hour timer shuts off the heat units when the curing cycle is complete, and the wheeled cart provides mobility around the shop or service area. The Lincoln-2500 operates on 120V at 11 amps.

Tire Vulcanizer Lincoln-2500 Specification

• Brand: LMC
• Model: Lincoln-2500
• Product Type: Multi-Use Tire Vulcanizer
• Application: Agricultural, skidder, construction, mining, and OTR tire repair
• Curing Head Size: 8" x 10" and 8" x 15"
• Number of Curing Heads: 2
• Throat Depth: 18"
• Throat Height: 32-1/2"
• Pressure: Over 5,000 lbs.
• Shipping Weight: 950 lbs.
• Shipping Volume: 50 cu. ft.
• Voltage: 120V
• Current: 11 amps

Lincoln-2500 Tire Vulcanizer Special Features:

• Designed for agricultural, skidder, construction, mining, and OTR tire repairs
• Handles tires from 20.5 x 25 up to 29.5 x 35
• Accommodates skidder tires up to 30.5 x 32
• Designed for tread, shoulder, and sidewall repairs
• Adjust-A-Plate contour system conforms to tire contours
• 8" x 11" inside contour plate
• 8" x 15" outside contour plate
• Air-actuated pressure applies over 5,000 lbs. evenly across the repair area
• Thermostatically controlled heat units maintain curing temperature
• Built-in five-hour timer automatically shuts off heat units after the curing cycle
• Quick-adjust tightening device
• Designed for one-person operation
• Wheeled cart provides mobility
• Available only in 120V, 11-amp configuration

LMC Lincoln-2500 Manual

  LMC Lincoln-2500 Instruction Manual

  LMC Lincoln-2500 Spec Sheet
