Mahle CWL-20, Commercial Vehicle Wheel Lift 20 Ton (Pair)

SKU CWL-20
by Mahle
  • Contact us now for our best price!
  • No Sales Tax - Except CA, FL, IL, IN, MI, & OH
  • Free Warehouse Pickup Options
  • Better Business Bureau (BBB) Accredited
$17,464.00
Address Type (Required Field)
Delivery Options (Required Field)

Notify me when back in stock

CWL-20, Commercial Vehicle Wheel Lift 20 Ton (Pair) By Mahle

Introducing the Mahle CWL-20 Commercial Vehicle Wheel Lift, a powerhouse of lifting capacity that can hoist up to 40,000 lbs per set. Designed with a sleek, low-profile frame, this wheel lift allows you to raise and lower entire vehicles effortlessly, thanks to its patented controls and dual trigger valves. Whether you're performing routine maintenance or preparing for a high-stakes operation, this lift takes the grunt work out of heavy lifting, freeing you up to focus on the job at hand.

The CWL-20 is ideal for shops with low ceilings, easily lifting vehicles up to 30 inches high while ensuring stability and safety. With small wheel adapters that accommodate a range of wheel sizes from 14 inches to 24.5 inches, this versatile lift can handle a variety of vehicles with ease. Designed to give you complete access underneath the vehicle, it includes a built-in support stand feature that enhances safety and efficiency. Consider the Mahle CWL-20 your ultimate lifting companion, ready to tackle any challenge that comes your way.

Vehicle Wheel Lift CWL-20 Specifications

  • Capacity Per Set: 40,000 lb (18,143 kg)
  • Minimum Start Height: Floor Level
  • Maximum Lift Height: 30 in (76 cm)
  • Power: Shop Air
  • Required Air Pressure: 160 psi (11 bar)
  • Stroke: 30 in (76 cm)
  • Minimum Wheel Diameter (with Adapters): 14 in (36 cm)
  • Minimum Wheel Diameter (without Adapters): 21 in (53 cm)
  • Maximum Wheel Diameter: 24.5 in (62 cm)
  • Dimensions (H x W x D): 63 in x 45 in x 44 in (160 cm x 114 cm x 112 cm)
  • Shipping Weight: 1,965 lb (891 kg)

CWL-20 Vehicle Wheel Lift Special Features

  • Built-in Vehicle Support Stand: Allows complete open access under the vehicle for maintenance and inspections.
  • Patented Controls: Effortlessly lift entire vehicles using shop air with precision.
  • Ideal for Low Ceilings: Designed to work in tight spaces, perfect for smaller shops.
  • Small Wheel Adapters: Accommodate wheel sizes from 14 inches to 24.5 inches.
  • Dual Trigger Control Valve: Ensures synchronized raising and lowering of vehicles for added safety.
  • Sold in Pairs: Provides balanced lifting for maximum efficiency.
  • Versatile Compatibility: Easily handles wheel sizes from 19.5 inches to 24.5 inches, with optional adapters for 16 inches to 19.5 inches.
  • US Patents: Features patented technology for enhanced performance and reliability.
