CSC-2200, ShopPRO 1 Ton Engine Hoist By Mahle
When it comes to tackling heavy engine work in your shop, the Mahle CSC-2200 ShopPRO 1-Ton Engine Hoist is your essential companion. Engineered for versatility and mobility, this hoist features large caster wheels that allow for smooth gliding into position, making it perfect for both compact workspaces and expansive bays. With an adjustable leg width, you can effortlessly maneuver the hoist to fit your specific needs, ensuring that you have the optimal setup for every job.
Capable of lifting up to 2,200 lbs when retracted and 1,900 lbs at center, the CSC-2200 is built for heavy-duty performance. Its boom extends to a maximum height of 125 inches, with an adjustable reach from 33 inches to 48 inches, giving you the clearance and control necessary for a variety of engine tasks. With a horizontal boom height of 83 inches, you can maintain balance and safety while working on those challenging engine swaps. Experience the ease and reliability of engine handling with the Mahle CSC-2200.
Engine Hoist CSC-2200 Specifications
-
Lifting Capacity:
- Retracted: 2,200 lbs (998 kg)
- Center: 1,900 lbs (862 kg)
- Extended: 1,650 lbs (748 kg)
-
Maximum Boom Height:
- Retracted: 114 in (290 cm)
- Extended: 125 in (318 cm)
-
Overall Boom Height (horizontal): 83 in (211 cm)
-
Boom Reach:
- Retracted: 33 in (84 cm)
- Extended: 48 in (122 cm)
-
Overall Length: 82 in (208 cm)
-
Minimum Throat Width: 22 in (56 cm)
-
Leg Length (inside): 55 in (140 cm)
-
Inside Leg Width: Adjustable to 22 in (56 cm), 36 in (91 cm), and 50 in (127 cm)
-
Leg Height: 8.1 in (21 cm)
-
Wheel Diameter: 6 in (15 cm)
CSC-2200 Engine Hoist Special Features
- High lifting capacity for heavy engine work
- Large caster wheels for easy mobility and positioning
- Adjustable leg width for versatile use in different spaces
- Boom extends up to 125 inches for maximum height
- Reach adjustment from 33 inches to 48 inches for varied tasks
- Durable construction for long-lasting performance
- Unit includes free shipping for added value
