Star-A-Liner Cheetah 20' Three Tower Frame Machine With Hydraulics

SKU 9011203
$26,146.00
  • Contact us now for our best price!
  • No Sales Tax - Except CA, FL, GA, IL, IN, MI, OH, & PA
  • Free Warehouse Pickup Options
  • Better Business Bureau (BBB) Accredited

Delivery Options

Notify me when back in stock

Star-A-Liner Cheetah 20' Three Tower Frame Machine with Hydraulics – Heavy-Duty Auto Body Rack

The Star-A-Liner Cheetah 20' Three Tower Frame Machine with Hydraulics is engineered for maximum pulling power and versatility in auto body repair. With a 20-foot bed, 360° pulling capability, and three hydraulic towers, this heavy-duty frame rack is built to handle everything from compact cars to extended cab trucks with ease. Its robust design, advanced hydraulics, and included clamp and chain package make it a reliable solution for high-volume repair shops seeking efficiency and durability.

This machine’s three-tower system provides precise, multi-angle pulling power that significantly reduces repair times. Each tower delivers up to 10 tons of hydraulic force, allowing technicians to straighten even the most severe frame damage. With its extended reach, wide treadway design, and easy loading ramps, the Cheetah 20' III ensures smooth workflow and improved productivity in busy collision repair facilities.

Designed for professional body shops, the Star-A-Liner not only delivers strength and stability but also incorporates features that enhance safety and operator convenience. From its powerful anchoring system to its air-powered hydraulics, this frame rack provides dependable performance for years of demanding use. If your shop requires a top-tier pulling and straightening solution, the Cheetah 20' Three Tower Frame Machine is the investment that will elevate your repair capabilities.

3 Tower Frame Machine CHEETAH 20 Specification

  • Part ID: 9011203 Cheetah 20’ III W/HYD

  • Length of Bed (Top): 20 ft. (610 cm)

  • Length with Towers Extended: 25 ft. 10 in. (785 cm)

  • Width of Bed: 92 in. (234 cm)

  • Width with Towers Extended: 14 ft. (427 cm)

  • Width of Treadway: 28 in. (71 cm)

  • Width Between Treadway: 36 in. (91 cm)

  • Overall Height: 8 ft. 6 in. (259 cm)

  • Tower Height: 6 ft. 8 in. (203 cm)

  • Working Height: 24 in. (61 cm)

  • Weight: 6,560 lbs. (2,975 kg)

  • Power Required – Hydraulics: 100 psi air (6.89 bar)

  • Pulling Power Hydraulics: 10 ton (9 metric ton) per tower

  • Pulling Radius: 360 degrees

Cheetah 20' 3 Tower Frame Machine Special Features

  • Heavy-duty three tower hydraulic design for maximum pulling versatility

  • 20-foot bed accommodates cars, trucks, and larger vehicles

  • 360° pulling radius allows precise pulls from any angle

  • 10-ton pulling power per tower for tough frame straightening jobs

  • Wide treadway and loading ramps for easy vehicle setup

  • Air-powered hydraulics for efficient operation

  • Built with durable steel construction for long-lasting shop use

  • Ideal for high-volume collision repair facilities

9011203 Cheetah 20 Manual

Coming Soon
