Our Super Duty SD10HO High-Output HVLS ceiling fan brings workhorse performance to any large space with a compact footprint. Its 750 W Permanent Magnet Synchronous Motor powers six dual-plane blades—each injection-molded with 30 patent-pending features like trailing-edge serrations, vortex generators, raked tips, and built-in pitch contours—to deliver ultra-quiet airflow over 13,250 ft² at up to 150 RPM. The VFD accepts standard 110 V input and converts it to 220 V 3-phase for smooth, reversible speed control, while the dual-plane hub system minimizes noise and maximizes air displacement.
Installation is remarkably simple thanks to our innovative telescoping down rod—no cutting or drilling—and a rugged guy-wire system for rock-solid stability. The IP20 controller (optionally housed in an IP67 enclosure) mounts on any wall, runs on 14/4 wiring, and accepts fire-suppression relays. Hubs and down rods ship in aluminum finish, with satin-black motor and mounts; blades arrive in black but can be custom-painted for volume orders.
Diameter: 10 ft
Number of Blades: 6
Overall Weight: 124 lbs
Max Speed: 150 RPM
Motor Power: 1 HP (750 W)
Min. Input Power: 110 V @ 16.1 A
Coverage Area: Up to 13,250 ft²
Radius of Effect: 65 ft
Min. Drop Clearance: 3 ft
Dual-plane hub system for whisper-quiet, high-volume airflow
Six injection-molded blades with 30 patent-pending aerodynamic enhancements
Telescoping down rod—no cutting or drilling required
VFD converts 110 V single-phase to 220 V 3-phase with ramp-up to minimize amp spikes
IP20 controller; optional IP67 enclosure for harsh environments
Fire-suppression relay compatibility
Guy-wire stability system (included)
Custom high-adhesion blade-painting options for bulk orders
Pre-assembled blades and hubs for faster installation
Warranties: 10 years (mechanical), 5 years (motor), 1 year (VFD)
