Corghi Artiglio 500M 28''Center Post Wheel Clamping Tire Changer

Artiglio 500M Center Post Tire Changer

The Corghi Artiglio 500M LL is engineered for professionals who need maximum performance in a compact footprint. Designed for mobile tire service vans and tight workshop spaces, this advanced tire changer delivers the same power and reliability as the original Artiglio 500—now in an even lighter and more space-efficient form. Its smart engineering makes it the ideal solution for shops that demand speed, precision, and versatility.

Equipped with a new center post wheel clamping system featuring two adjustable working heights, the Artiglio 500M LL accommodates a wide range of wheels with ease. The Smart Lever Less System removes operator strain while maintaining excellent control during mounting and demounting. Combined with its ergonomic working layout, technicians can complete jobs faster with less fatigue and greater consistency.

From dual bead-breaking discs to its rapid second bead removal system, every detail is designed for maximum efficiency. Whether handling Run Flat, Low Profile, or conventional tires, this machine ensures safe, fast, and repeatable results. For shops, fleet operators, and mobile tire businesses, the Artiglio 500M LL delivers premium performance without requiring extra space.

Corghi 500M Specifications

• Rim Diameter: 12" – 28"

• Maximum Tire Diameter: 44"

• Maximum Tire Width: 15"

• Rotation Torque: 811.8 ft-lb

• Rotation Speed: 7 – 18 rpm

• Bead Breaker Range: 26.4"

• Bead Breaker Stroke: 21.2"

• Bead Breaking Force: 1,710 lb

• Maximum Wheel Weight: 187.4 lb

• Power Requirement: 1-phase, 230V or 110V, 0.98 kW, 50/60 Hz

• Minimum Air Pressure: 116 PSI

• Machine Weight: 837.7 lb

• Height: 72.5"

• Depth: 65.5"

• Width: 56"

Artiglio 500M Tire Changer Special Features

• Compact and lightweight structure ideal for vans and small workshops

• Two-position center post wheel clamping for flexible wheel handling

• Smart Lever Less System eliminates the need for manual levers

• Dual bead-breaking discs with patented controlled penetration

• Rapid second bead demounting for stiff or Run Flat tires

• Ergonomic control layout for faster, more comfortable operation

• Lightweight swing arm with Fast & Smart release system

• Safe, universal center clamping for all wheel types

• Compatible with optional wheel lifter and multiple accessory kits

Artiglio 500M Manual

  Corghi Artiglio 500M Brochure
