KT-X80 Mid Rise Scissor Lift by Katool
Is your current car maintenance routine a circus act, contorting yourself into uncomfortable positions to reach that leaky oil filter? Say goodbye to the struggle with the Katool KT-X80 Mid-Rise Scissor Lift. This isn't your average lift as it can handle up to a whopping 8,000 lbs, so even the beefiest of vehicles won't be a problem. Need to get up close and personal with a car's undercarriage? No sweat! The KT-X80 adjusts to heights between 4.25 and 41.25 inches, giving you all the access you need.
Think tight spaces are a nightmare? This scissor lift defies the laws of physics (almost) with a surprisingly compact design that squeezes through narrow gaps at a mere 73.25 inches wide. Need it to stay put? No problem, it can be fixed or mounted mobile for ultimate versatility. The KT-X80 has an electric lock, a secure 24V control system, and an electric safety release mechanism – all working in beautiful harmony to keep you safe and sound. What’s not to like?
Scissor Lift KT-X80 Specifications:
- Lifting Capacity: 8000lbs
- Max Lifting Height: 41.25"
- Min Lifting Height: 4.25"
- Platform Length: 56.25"
- Platform Width: 19.5"
- Length Overall: 80"
- Width Overall: 73.25"
- Weight: 1213 lbs
- Oil: AW-46 or AW-32 (colder climates)
-
Optional: Support Bars
- Overall Length: 73"
- Pin Distance: 48" to 59" Wide
- Adapter Height: 6.2" to 8" Tall
KT-X80 From Katool Special Features:
- Lock Style: Electric
- Certification: CE Approved and Certified. (115% dynamic loading capacity standard and was 150% static loading capacity tested)
- Mount design: Mobile or Fixed
- Starting-up system design
- Safety release: Electric
- 24V safe control system
- Limit switch prevents over lifting.
- Composite rubber lifting blocks included
- Comes with self-lubricated bushing and bearing
- Drive-up ramps lock in place for longer vehicles
- Top-level hydraulic system and aluminum motor with the fan prevents overheating. on top to avoid overheating
- Power Options: 110V or 220v
- Includes: Caster Kit for Mobility
- Katool Warranty:
- One-year (12 months) warranty on all parts and against all product defects, free of charge to our customers, on all equipment
- Vehicle lifts will include an additional three-year (36 months) warranty on all lift structural components only.
Katool KT-X80 Documentation:
Katool KT-X80 Scissor Lift Product Manual
This Item has a FLAT RATE SHIPPING FEE: $199*
Warehouse Pickup locations (free shipping) - Contact Us if interested.
- City of Industry, CA 91789
- Brookshire, TX 77423
- Houston, TX 77064
- Pooler, GA 31322
- Jersey City, NJ 07305
- Bolingbrook, IL 60440
Pallet Dimensions:
- Lift: 78" x 64" x 9" - 1213lbs
- Control Unit: 17" x 15" x 43" - 132lbs
