Our Super Duty SD15HO High-Output HVLS ceiling fan redefines large-area climate control with massive, whisper-quiet airflow. Powered by an 1,100 W Permanent Magnet Synchronous Motor (PMSM), its six dual-hub blades—each injection-molded with 30 patent-pending features like trailing-edge serrations, vortex generators, raked tips, and built-in pitch contours—move air across 17,650 ft² at up to 95 RPM. The smart variable-frequency drive (VFD) pairs with a standard 220 V single-phase feed to deliver smooth, reversible speed control with minimal amp spikes and over-torque. Installation couldn’t be simpler: a telescoping down rod negates cutting or drilling, and the rugged guy-wire system ensures unwavering stability.
Built for durability and flexibility, the SD15HO includes an IP20 VFD controller (optionally housed in IP67) that accepts fire-suppression relays and mounts neatly on any wall. Hubs and down rods sport an aluminum finish, while the motor and mounts are satin black. Blades arrive in black but can be custom-painted with high-adhesion colors for large orders.
Diameter: 15 ft
Number of Blades: 6
Overall Weight: 141 lbs
Max Speed: 95 RPM
Motor Power: 1.5 HP (1100 W, 220 V/1 Ph)
Input Power: 220 V, 1 Phase
Coverage Area: Up to 17,650 ft²
Radius of Effect: 75 ft
Min. Drop Clearance: 3 ft
Six dual-hub injection-molded blades with 30 patent-pending aerodynamic enhancements
Telescoping down rod—no cutting or drilling required
VFD with factory-set ramp-up for smooth, reversible speed control
IP20 controller; optional IP67 enclosure for harsh environments
Fire-suppression relay compatibility
Guy-wire stability system (included)
Custom blade-painting options for volume orders
Aluminum-finished hubs and rods; satin-black motor and mounts
Pre-assembled blades and hubs for faster installation
Warranties: 10 years (mechanical), 5 years (motor), 1 year (VFD)
